Description
The HI-99301 is a portable, EC/TDS/temperature meter that measures high range conductivity in mS/cm and TDS in ppt. Both instruments are housed in a case rated for IP67 conditions. This instrument offers single point, automatic calibration with automatically temperature compensated measurements. The compensation coefficient and EC/TDS conversion factor are user-selectable from 0.45 to 1.00 and temperature coefficient is selectable from 0.0 to 2.4%/°C. This meter easily fits in the palm of your hand and the bottom probe connection ensures the electrode cable doesn’t get in your way. The large, multi-level LCD displays the primary reading, temperature and calibration guides simultaneously. Symbols and messages on the LCD indicate meter status and guides users through operations. At start-up, the meter shows the remaining battery percentage and when a low battery condition is detected, a battery symbol appears on the LCD to advise the user that only a few hours of working time is left. The HI-76306 EC/TDS/temperature probe resists clogging and is easy to clean. Ideal for: Boiler Water & Waste Water Main features Simultaneous EC/TDS and temperature measurements on a large LCD display Selectable temperature unit HI-763063 dedicated EC/TDS temperature probe Probe quick connect system Battery life indication and low battery detection Auto-off function Keystroke confirmation tone Waterproof casing IP67 Each meter is supplied complete with: HI-763063 pH/EC/TDS probe with built-in temperature sensor, DIN connector and 1m cable HI-70030 – 12880 µS/cm and HI-70038 6.44 ppt 1 sachet each 100mL beaker Alkaline batteries: 1.5V AAA x 3 Rugged carrying case Calibration certificate of meter Calibration certificate of probe Instruction manual Range EC 0 to 20.00 mS/cm (displays mS) TDS 0.00 to 10.00ppt Temp -5.0 to 105.0°C Resolution EC 0.01 mS/cm TDS 0.01 ppt (g/L) Temp 0.1°C Accuracy @ 20°C ±2% F.S. (EC/TDS); ±0.5°C temp Temperature Compensation Automatic, with β selectable from 0.0 to 2.4%/°C with 0.1 increments EC/TDS Calibration Automatic, one-point at 12.88mS/cm or 6.44 ppt (CONV=0.5) or 9.02 ppt (CONV=0.7) TDS Conversion factor Selectable from 0.45 to 1.00 with 0.01 increments Probe (included) HI-763063 EC/TDS/Temperature sensor, DIN connector and 1m cable Battery type/life 1.5V AAA x 3 approx 500 hours of continuous use Auto off User selectable after 8 mins, 60 mins or disabled Environment 0 to 50°C RH max 100% Meter Dimensions 154 x 63 x 30mm Weight (with batteries) 196g Casing ingress protection rating IP67
